| 1 | 03414060124 | Inner Hexagonalobular Socket Pan Head Screw M6×12 (Black) | |
| 2 | 04922060025 | Plate Nut (Long) M6 | |
| 3 | 17010202810 | Left Side Board (2) | |
| 4 | 17010202870 | Left Side Board 1 (True Timber) | |
| 4 | 17010203060 | Left Side Board 1 (Black) | |
| 4 | 17010203160 | Left Side Board 1 (Titanium Gray) | |
| 4 | 17010203080 | Left Side Board 1 (Red With Flake) | |
| 4 | 17010203350 | LH Side Board 1, Sand Gold | |
| 4 | 17010203200 | Driver Side Side Panel (1) (Metallic Blue) | |
| 4 | 17010202840 | Left Side Board 1 (Cyber Gray) | |
| 4 | 17010202920 | Left Side Board 1 (Pearl White) | |
| 4 | 17010203110 | Left Side Board 1 (Injection White) | |
| 4 | 17010203280 | Left Side Board 1 (Magic Flame Green) | |
| 4 | 17010203470 | Left Side Board 1 (Army Green) | |
| 4 | 17010203510 | Left Side Board 1 (Desert Brown) | |
| 4 | 17010203550 | Left Side Board 1 (Glacier Silver) | |
| 4 | 17010203590 | Left Side Board 1 (Injection Green) | |
| 5 | 17009160220 | Dash Display Base | |
| 6 | 10410190000 | Push Pin M8×15 | |
| 7 | 17009010260 | Electrical Mounting Board | |
| 8 | 17010202370 | Left Side Board (3) | |
| 9 | 16110750001 | Buckle | |
| 10 | 03714350164 | Tapping Screws ST3.5×16 | |
| 11 | 06119040905 | Washer φ4×φ9×1 | |
| 12 | 04922050024 | Plate Nut M5 | |
| 13 | 01224050125 | Hex Flange Bolt M5×12 | |
| 14 | 17009090130 | Seat Saddle Lower Guard Board | |
| 15 | 17010202820 | Right Side Board (2) | |
| 16 | 17010202880 | Right Side Board 1 (True Timber) | |
| 16 | 17010203070 | Right Side Board 1 (Black) | |
| 16 | 17010203360 | Right Side Board 1 | |
| 16 | 17010203170 | Right Side Board 1 (Titanium Gray) | |
| 16 | 17010203090 | Right Side Board 1 (Red With Flake) | |
| 16 | 17010203210 | Passenger Side Side Panel (1) (Metallic Blue) | |
| 16 | 17010202850 | Right Side Board 1 (Cyber Gray) | |
| 16 | 17010202930 | Right Side Board 1 (Pearl White) | |
| 16 | 17010203120 | Right Side Board 1 (Injection White) | |
| 16 | 17010203290 | Right Side Board 1 (Magic Flame Green) | |
| 16 | 17010203480 | Right Side Board 1 (Army Green) | |
| 16 | 17010203520 | Right Side Board 1 (Desert Brown) | |
| 16 | 17010203560 | Right Side Board 1 (Glacier Silver) | |
| 16 | 17010203600 | Right Side Board 1 (Injection Green) | |
| 17 | 04522080026 | Hex Flange Locking Nut M8 | |
| 18 | 17310360000 | Hand Shifting Board (ATV1000 Only) | |
| 19 | 01224080306 | Hex Flange Bolt M8×30 | |
| 20 | 17010202510 | Right Side Board (3) | |
| 21 | 13610630071 | Storage Box Rubber Strip | |
| 22 | 17010280140 | Seat Guard Board Top Cover | |
| 23 | 17010280000 | Seat Guard Board | |
| 24 | 17010202070 | LH Side Plate Heat Insulation Film | |
| 25 | 17010202080 | RH Side Plate Heat Insulation Film | |
